Circle Systems Water Based Mi-Glow #634

Circle Systems Water Based Mi-Glow #634

Dual Red Particles

Photo taken in room illuminated to 100 ft. candles of visible light and 8,000 uw/cm2 of UV at > 15” distance.

Overview

Mi-Glow® 600 red particles premixed with powdered Wetting Agent 34 for use in water media. It is designed to be used with visible light for detecting discontinuities found in structural fabrications and weldments. Higher particle concentration provides heavier indication buildup for easy detection. Mi-Glow® 634 can be further enhanced when used with a black light or blue light.

Features

  • Borate free - wetting agent with excellent wetting characteristics
  • Low foaming – Well controlled water conditioning agents
  • Can be - used with UV-A, white light, and blue light
  • Provides total particle encapsulation, eliminating free unbonded pigment, resulting in a low background, high performing magnetic particle inspection powder
  • The particles have larger surface areas which mean smaller sized particles with increased sensitivity and brightness

Technical Specifications

Technical Specifications

Circle Systems Mi-Glow 634 Technical Specifications
Physical Characteristics Red powder with a slight detergent odor
Particle Certification Particles meet or exceed all relevant industry specifications. Certification is included with each shipment.
Particle Color Red
Average Particle Size 10 μm
AMS Standard N/A
SAE Sensitivity* N/A
Temperature Range 32-120°F (0-49°C)

*Representative of the number of lines shown on a steel tool ring as defined in SAE AS5282.

Dual Response (Visible and Fluorescent) Magnetic P

Dual Response (Visible and Fluorescent) Magnetic Particle Materials

Dual response magnetic particles have the following benefits:
When used to replace dry visible magnetic particles under visible light, they have sharper, more defined indications. Adding a hand-held UV lamp significantly improves sensitivity and detectability (indications “pop”)

When code requirements do not apply, or can be waved, inspection is possible with a fully illuminated surface (~100 ft. candles of visible light) using an ultra-high intensity UV lamp, which are now commonly available (> 7,000 uw/cm2 is recommended). The benefit of this is that a darkened booth is not needed, eye adaptation to the dark is also not required), added convenience, better air circulation and for those of us that get claustrophobic it is a great benefit.

Spray Cans

Pump Sprayer

Bulk

CircleSafe 850A

water carrier with liquid wetting agent, CO2 propellant (fume free)

CircleSafe 850S

water carrier with liquid wetting agent

CircleSafe 634

Concentrate with powder wetting agent to mix with water

Note: There is a $25 small order fee for orders valued less than $500. Can combine with other products to reach minimum.

Product Literature

Description Part # Saved Price Select Option Add to
Mi-Glow 634 - 2 lb. Jar MT-CS-FG-3661 $175.00
Mi-Glow 634 - 30 lb. Pail MT-CS-FG-3662 $2,240.00
