Glycerin can be used as a general purpose couplant. The viscosity and acoustic impedance are desirable for rough surfaces and highly attenuating materials. Glycerin has an acoustic impedance of 2.42 x 105 gm-cm2 / sec.

Glycerin is also suitable for use in high frequency delay line inspections, high frequency delay line thickness gauging and contact transducer testing on reference standards.

Product Description

 Product Specifications



Benefits:

  • Batch certified by 3rd party laboratory for Halogens (CI, BR, I, F) and Sulfar (S).
  • Packaged from USP Glycerin, 99+%
  • High acoustic impedance
  • Medium viscosity fluid
  • Will not harden on equipment
  • Pumpable liquid
  • Boiling Point: 550°F / 290°C
  • Compatible with plastics


Safety:

  • Non-toxic, non-irritating
  • Contains no heavy metals, harsh surfactants, glycol ethers, nitrites, silicones, dyes or fragrances.

    Corrosion:
    Glycerin can be corrosive to carbon steel and aluminum. No corrosion effect in most plastics, fiberglass or composites.

    Chemistry:
    Total Halogens: < 50 ppm
    Sulfar: < 50 ppm

    Temperature Range: 65° to 500°F / 18°C to 260°C

    Packaging:
    Carton of twelve 4 oz (118 ml) bottles
    1-gallon / 3.8 liter
    5 gallon / 18.9 liter


    Removal:     Can be completely removed with mild detergent and a water wash, or water wash alone.

    Note: Minimum order for Echo Couplant is $75. For orders that do not meet our minimum, there will be a $25 small order processing fee.

    Description Part # Saved Price Select Option Add to
    Echo Ultrasonics Glycerin Ultrasonic Couplant Carton of twelve 4 oz. - 118 ml bottles UT-EU-GLY-4CTN
    		$176.00
    Echo Ultrasonics Glycerin Ultrasonic Couplant 1 gallon - 3.8 liter, 1 bottle and dispensing cap (minimum 2) UT-EU-GLY-1
    		$146.00
    Echo Ultrasonics Glycerin Ultrasonic Couplant 5 gallon - 18.9 liter, 2 bottles and dispensing faucet UT-EU-GLY-5
    		$658.00
