Overview

Individual NAVSHIPS 250 -1500 (NAVSEA 271) Penetrameters come in a full range of thicknesses, sizes and materials. A notch system, in 5 groups, is used on the IQI to identify materials in order of increased attenuation, and lead figures identify the thickness of the material to be radiographed on the other end. In addition, the material and specification are etched into the IQI. Serialization and Calibration are available, as well as Encapsulation in clear, thin plastic and Wood Cases. Wood cases come in two sizes for encapsulated and non-encapsulated IQIs, and are engineered to prevent loss and damage by keeping IQI's firmly in place using a shock absorbing sponge rubber insert in the lid.

Penetrameter Sets and Shims, Mounting Blocks & Step Wedges are also available

NAVSHIPS 250 -1500 IQI Sets  Shims, Mounting Blocks & Step Wedges



Notching System

Material Notches
Steel, Stainless Steel, Manganese No notches
Aluminum-Bronze; Nickel-Aluminum-Bronze 1 notch on end
Inconel 2 notches on end
Nickel, Copper, Monel, Cupro-Nickel 1 notch on top edge
Tin Bronze, Valve Bronze 2 notches on top edge

Technical Specifications

General Dimensions & Thickness

General Dimensions

 Size Length Width  Image
 2.5" and smaller  1 1/2"  1/2"
 2.6" to 8"  2 1/4"  1"
Over 8" Diameter equal to 4 x Thickness Diameter equal to 4 x Thickness
(# of holes: 2)



Thickness

2% of the thickness of the material to be radiographed, to the nearest fractional size. Minimum thickness: 0.005"

Thickness Guide for Plaque Type IQI's

Hole Sizes

Small Hole Diameter 1 x Thickness (min: 0.010")
Medium Hole Diameter 2 x Thickness (min: 0.020")
Large Hole Diameter 4 x Thickness (min: 0.040")
Materials & Sizes

Sizes

Available in a range from .01" to 20.0"

Note: IQI's under .25" will be marked with the requested size, but will have the same thickness and hole sizes as a .25" IQI. If true 2% thickness IQI's are required for sizes under .25”, see Pratt & Whitney IQI's

Available Materials

  • Aluminum (6061)
  • Steel (1018)
  • Stainless Steel (304)
  • Aluminum 2014, 2024, 2219, 7075
  • Aluminum-Bronze
  • Brass
  • Copper
  • Cupro-Nickel
  • Inconel 600
  • Magnesium AZ 31 & ZK60
  • Monel 400
  • Nickel
  • Phosphor-Bronze
  • Cobalt (Haynes 25, Haynes 188)
  • Hastelloy (C or X)
  • Inconel 625 & 718
  • Plastics / Nylon
  • Rene 41
  • Titanium
  • Waspaloy
  • Zirconium

Minimum Order Size is $75

Note: Serialized radiographic products are not returnable

Product Literature

Description Part # Saved Price Select Option Add to
Individual IQI, NAVSHIPS 250 -1500 (NAVSEA 271), Plaque Type RT-RC-P-NAVSEA271 Request Pricing
