Maurer Magnetic CT Loop Demagnetizers

Maurer Magnetic CT Loop Demagnetizers

60 Hz AC Powered Tunnel Demagnetizing Coils for Industrial Applications





Heavy Duty - 100% Duty Cycle

The CT series tunnel demagnetizers are robust, 100% Duty Cycle, demagnetizing coils based on tried and tested technology. Magnetized parts are continuously fed through the coil and are demagnetized while being fed out along the coil axis.

Features & Applications

  • CT Coils reliably demagnetize high permeability parts up to a thickness of 0.8” (20mm).
  • When short parts are demagnetized, the penetration depth of the field is less than 0.4” (10mm).
  • Hard magnetic materials are not fully demagnetized by these or similar AC coils.
  • We offer higher power/lower frequency demagnetizers for difficult applications
  • It should be noted that smaller coils have a stronger magnetic field than larger coils.
  • Sturdy, for shop floor use
  • Particularly suitable for low alloy, high permeability, oblong steel parts
  • The demagnetizing coils are fed directly from your 220V AC 1-Phase circuit.
  • CE certified and complies with all current common standards
  • The variety of model sizes ensures enough versatility to handle whatever needs you may have

Maurer Magnetic Units Converter

Click Here to Use the Magnetic Units Converter

Technical Specifications

CT1 Model

External Dimensions: 6.7"L x 17.76"W x 11.10"H (170 x 451 x 282 mm)

Opening Dimensions: 4.72"L x 5.91"W x 3.94"H (120 x 150 x 100 mm)

Weight: 90.39 lbs (41 kg)

Degree of Protection IP: 50

Maximum Field Strength: 314 Gauss (25 kA/m)

Outlet Section: 19.69" (500 mm)

Duty Cycle: S1, 100%

Power Supply: 1NPE 200 – 240 VAC, 50/60 Hz

Device Protection: A, 6.3

CT2 Model

External Dimensions: 7.28"L x 22.09"W x 12.40"H (185 x 561 x 315 mm)

Opening Dimensions: 5.31"L x 10.24"W x 5.12"H (135 x 260 x 130 mm)

Weight: 136.69 lbs (62 kg)

Degree of Protection IP: 50

Maximum Field Strength: 362 Gauss (29 kA/m)

Outlet Section: 30.71" (780 mm)

Duty Cycle: S1, 100%

Power Supply: 1NPE 200 – 240 VAC, 50/60 Hz

Device Protection: A, 14

CT3 Model

External Dimensions: 7.87"L x 21.89"W x 17.13"H (200 x 556 x 435 mm)

Opening Dimensions: 5.91"L x 9.84"W x 9.84"H (150 x 250 x 250 mm)

Weight: 185.19 lbs (84 kg)

Degree of Protection IP: 50

Maximum Field Strength: 251 Gauss (20 kA/m)

Outlet Section: 39.37" (1000 mm)

Duty Cycle: S1, 100%

Power Supply: 1NPE 200 – 240 VAC, 50/60 Hz

Device Protection: A, 18

CT4 Model

External Dimensions: 9.84"L x 27.44"W x 15.16"H (250 x 697 x 385 mm)

Opening Dimensions: 7.87"L x 15.75"W x 7.87"H (200 x 400 x 200 mm)

Weight: 242.51 lbs (110 kg)

Degree of Protection IP: 50

Maximum Field Strength: 326 Gauss (26 kA/m)

Outlet Section: 47.24" (1200mm)

Duty Cycle: S1, 100%

Power Supply: 1NPE 200 – 240 VAC, 50/60 Hz

Device Protection: A, 23

CT5 Model

External Dimensions: 9.84"L x 27.80"W x 21.06"H (250 x 706 x 535 mm)

Opening Dimensions: 7.87"L x 15.75"W x 13.78"H (200 x 400 x 350 mm)

Weight: 264.56 lbs (120 kg)

Degree of Protection IP: 50

Maximum Field Strength: 226 Gauss (18 kA/m)

Outlet Section: 59.06" (1500 mm)

Duty Cycle: S1, 100%

Power Supply: 1NPE 200 – 240 VAC, 50/60 Hz

Device Protection: A, 32

CT6 Model

External Dimensions: 9.84"L x 26.42"W x 21.85"H (250 x 671 x 555 mm)

Opening Dimensions: 8.66"L x 15.75"W x 15.75"H (220 x 400 x 400 mm)

Weight: 286.6 lbs (130 kg)

Degree of Protection IP: 50

Maximum Field Strength: 213 Gauss (17 kA/m)

Outlet Section: 62.99" (1600 mm)

Duty Cycle: S1, 100%

Power Supply: 12PE 400 – 480 VAC, 50/60 Hz

Device Protection: A, 32

CT7 Model

External Dimensions: 14.45"L x 33.43"W x 28.94"H (367 x 849 x 735 mm)

Opening Dimensions: 13.27"L x 21.65"W x 21.65"H (337 x 550 x 550 mm)

Weight: 418.88 lbs (190 kg)

Degree of Protection IP: 50

Maximum Field Strength: 138 Gauss (11 kA/m)

Outlet Section: 86.61" (2200 mm)

Duty Cycle: S1, 100%

Power Supply: 12PE 400 – 480 VAC, 50/60 Hz

Device Protection: A, 32

CT8 Model

External Dimensions: 14.17"L x 41.18"W x 28.94"H (360 x 1046 x 735 mm)

Opening Dimensions: 12.99"L x 29.53"W x 21.65"H (330 x 750 x 550 mm)

Weight: 507.06 lbs (230kg)

Degree of Protection IP: 50

Maximum Field Strength: 113 Gauss (9 kA/m)

Outlet Section: 102.36" (2600 mm)

Duty Cycle: S1, 100%

Power Supply: 12PE 400 – 480 VAC, 50/60 Hz

Device Protection: A, 32

Product Literature

Description Part # Saved Price Select Option Add to
CT1 - 230VAC / 60Hz DE-MM-T-00400
Request Pricing
CT2 - 230VAC / 60Hz DE-MM-T-00410
Request Pricing
CT3 - 230VAC / 60Hz DE-MM-T-00420
Request Pricing
CT4 - 230VAC / 60Hz DE-MM-T-00430
Request Pricing
CT5 - 230VAC / 60Hz DE-MM-T-00440
Request Pricing
CT6 - 230VAC / 60Hz DE-MM-T-00450
Request Pricing
CT7 - 230VAC / 60Hz DE-MM-T-00460
Request Pricing
CT8 - 480VAC / 60Hz DE-MM-T-00470
Request Pricing
