Uniflux Microflux Magnetic Particle Bench

Uniflux Microflux Magnetic Particle Bench

The Microflux is equipped as standard with two phased-shifted magnetization circuits. These can be used individually or in combination.


  • For each magnetization circuit with a digital contact measuring instrument
  • Every magnetization circuit with an electronic power controller
  • Programmable logic controller made by Siemens
  • Continuous intensity control for longitudinal and circular magnetization
  • Selector switch on / off for longitudinal and circular magnetization
  • Selector switch on / off for demagnetization of longitudinal and circular magnetization
  • Selector switch manual / automatic
  • Time relay for setting the magnetization duration
  • Control push button on / off
  • Socket for the test equipment pump
  • Emergency stop switch on the control cabinet
  • All adjustable elements are covered by a plexiglass cover
  • Foot switch according to UVV

Microflux - side


Execution of the test bench (mechanical):

  • Ergonomically designed base, oil-resistant lacquered
  • The left tensioning side (coil) is permanently mounted; the quill is built into it.
  • Pneumatically operated short stroke cylinder of 0.28" (7 mm) moveable for tensioning / relaxing.
  • The magnetizing sleeves are made from laminated transformer sheets.
  • The right clamping side can be moved on a trolley to adjust the clamping length. This trolley is
    mounted with liquid-tight ball bearings in 4 collar rollers and is easy to move.
  • 2 parallel tracks are used for guidance
  • The pole carriage can be brought to the respective workpiece length using a clamping lever
  • The 2 magnetization quills are equipped with easily exchangeable contact plates.
    Diameter D = 200 mm (8").
  • Conical liquid container made of stainless steel with a capacity of 10.6 gallons (40 liters)
  • Hand hose & area shower for flushing
  • Clamping length 27.6" (700 mm)
  • Compressed air maintenance unit 1/4"
  • Hard plastic part supports headstock and tailstock

Microflux in lab

Technical Specifications:

  • Current flow: For the detection of longitudinal cracks alternating current
    max. 3000 A effective
  • Field flow: For the detection of transverse cracks in alternating currents
    max. 15kAW
  • Duty Cycle: 60% absolute, 10 second in - 20 seconds out
  • Mains connection: 3 x 500 V (or as requested by the customer)
  • Control voltage: 24V DC
  • Frequency: 60 Hz
  • Power consumption: approx. 24 kVA
  • Clamping length: 0.8" x 27.6" (20 - 700 mm)
  • Workpiece weight: max. 220 lbs. (100 kg)
  • Compressed air: 5 bar
  • Weight test bench: approx. 1900 lbs. (850 kg)

Microflux -front
