Conventional UT |
Phased Array |
| Pulsers |
| Configuration |
2 UT Channels |
16:16 or 16:64 |
| Test Mode |
Pulse-Echo, Transmit/Receive and TOFD |
Pulse-Echo, Transmit/Receive |
| Transducer Socket |
LEMO 1 or BNC |
I-PEX |
| Pulse Voltage |
-100V to -450V (in steps of 10V) |
-25V to 75V (in steps of 5V) |
| PRF |
1 Hz to 1500 Hz |
1 Hz to 5000 Hz |
| Pulse Shape |
Negative Square Wave (with ActiveEdge) |
Negative Square Wave (with ActiveEdge) |
| Pulse Width |
Adjustable: Spike to 2000ns (2.5ns resolution) |
Adjustable: Spike to 1000ns (2.5ns resolution) |
| Edge Time |
15 ns in 50 Ω load @ 200V |
12 ns in 50 Ω load @50V |
| Output Impedance |
5 Ω |
<10 Ω |
| Trigger Synchronization |
On encoder resolution or internal PRF (both encoded or not) |
On encoder resolution or internal PRF (not encoded) |
| Focus Delay Range |
N/A |
0 to 10 μs (2.5 ns resolution) |
| Damping Resistor |
Selectable 50 Ω or 400 Ω |
N/A |
| Receivers |
| Gain Range |
100 dB (0.1 dB steps) Analogue Gain |
0 to 76 dB (0.1 dB steps) Analogue Gain |
| Max Input Voltage |
25 Vp-p |
200 mVp-p |
| Input Impedance |
1 kΩ (pitch and catch) |
200 Ω |
| Bandwidth |
200 kHz to 22 MHz (-3 dB) |
200 kHz to 14 MHz |
| Analog Filters |
4 (automatic or manual) |
3 (automatic) |
| Digital Filters |
10 (automatic or manual) |
10 (automatic or manual) |
| Rectification |
Full wave, positive, negative, none (RF) |
Full wave, positive, negative, none (RF) |
| Signal Enhancement |
Digital filters, Smoothing, Contouring, Rejection, Averaging |
Digital filters, Smoothing, Contouring, Rejection |
| Focus Delay Range |
N/A |
0 to 10μs (16ns resolution interpolated to 3.8ns) |
| Data Acquisition |
| Architecture |
2 channels, true 200 MHz sampling rate |
16 channels, Full Digital Delay & Sum |
| Digitizer Resolution |
12 bit ADC |
12 bit ADC |
| Amplitude Measurement |
[0% to 100%] or [0% to 150%] FSH |
[0% to 100%] or [0% to 150%] FSH |
| Data Processing |
16 bit/sample |
16 bit/sample |
| Data Recording |
Full raw data recording (plus sub-sampling options) |
Full raw data recording (plus sub-sampling options) |
| File Size |
Up to 3 GB |
Up to 3 GB |
| Digitizing Frequency |
50 MHz, 100 MHz, 200 MHz |
65 MHz |
| Focal Laws |
N/A |
128 |
| Focusing Mode |
N/A |
Natural or constant depth/path/offset |
| Max A-Scan Length |
8192 samples |
4096 samples |
| Sub-Sampling |
1:1 to 1:28 |
1:1 to 1:28 |
| Reference |
Initial Pulse or Gate/IFT supported |
Initial Pulse or Gate/IFT supported |
| Trigger Sync. |
Encoder or Internal |
Encoder or Internal |
| Scan & Views |
| Supported Scans |
A-Scan & TOFD |
S-Scan & L-Scan |
| Number of Scans |
Up to 2 |
1 (with up to 3 extracted A-Scans) |
| Views |
A, B, C-Scan, Merged & TOFD |
A, B, C, L, S-Scan, Merged plus true TOP & END |
| Color Maps |
Up to 10 |
Up to 10 |
| Number of Layouts |
18 |
35 |
| Cursors |
| Cursor Types |
Cartesian, Hyperbolic (TOFD) |
Cartesian, Extraction Box, Angular |
| Measurements |
Path Length, Depth, Surface Distance, DAC, AWS, DGS |
Path Length, Depth, Surface Distance, DAC, AWS |
| DAC & TCG |
| DAC Points |
16 |
16 |
| DAC |
1 with 3 "sub DACs" |
1 with 3 "sub DACs" per focal Law |
| TCG Points |
16 |
16 |
| Gain Range |
60 dB |
40 dB |
| Max Gain Slope |
60 dB/μs |
50 dB/μs |
| Gates |
| A-Scan Gates |
4 gates per A-Scan |
4 gates per A-Scan (3 extracted A-Scans per S/L-Scan) |
| Gate Trigger |
Flank/Peak |
Flank/Gate |
| S/L-Scan |
N/A |
1 Extraction Box |
| Alarm LED |
2 (sync on all gates & DACs) |
2 (sync on all gates & DACs) |
| Measurements (A-Scan) |
Peak & Flank (FSH, dB, Depth, Beam Path Length, Surface Distance), Echo-to-Echo, Floating Gates (reference from IFT) |
Peak & Flank (FSH, dB, Depth, Beam Path Length, Surface Distance), Echo-to-Echo, Floating Gates (reference from IFT) |
| Interface & Reporting |
| Integrated Help |
Active help & parameter description / Optimization |
| Remote Connection |
Onboard VNC Server and FTP Server (connection through Ethernet protocol) |
| Wizards |
Configuration, Velocity and Zero, Wedge Delay, Sensitivity, TCG, DAC, DGS, Element Activation, Encoder |
| Languages |
Selectable: English, German, French, Spanish, Russian, Chinese, Hungarian, Italian, Portuguese |
| Report Generation |
PDF Report (includes customer logo, scan acoustic parameters, measurements, etc.), PNG screen capture. |
| PDF Reader |
Allows viewing any uploaded PDF file, scan plan, procedures, old reports etc.. |
| Inputs & Outputs |
| Encoder |
1 or 2 axis encoding (quadrature input) |
| Digital Inputs |
2 input lines (5V TTL) |
| Digital Outputs |
4 Output lines (5V TTL, 20mA) for alarm or other external control |
| Power Output |
5V, 350 mA, current limited |
| Enclosure |
| Dimensions |
205 x 300 x 90mm |
| Weight |
3.5 kg with battery |
| Display Size |
8.4" (diagonal) |
| Display Resolution |
800 x 640 pixels |
| Display Colors |
260k (65535 colors for scan palettes) |
| Display Type |
TFT LCD, 450 Cd/m2, with 2% reflectivity |
| USB Ports |
3 USB Master ports |
| Ethernet |
100 Mbps |
| Battery & Power Supply |
| Battery Type |
Intelligent Li-ion |
| Number of Batteries |
1 |
| Operation |
On battery or on External Power (DC Power Pack) |
| Battery Replacement |
Yes, no tools required |
| Battery Recharge |
Recharge in unit (with unit On or OFF) - External Battery Charger (std) (as per EN16392) |
| Battery Life |
Typical: 7 hours in UT mode, 6 hours in PA mode |
| Environmental |
| IP Rating |
Designed to meet IP66 |
| Operating Temperature |
14°F to 113°F (-10°C to 45°C) |
| Storage Temperature |
-13°F to 140°F (-25°C to 60°C) |
