The MXY-4000 is a low-mass, low-profile manipulator that maintains broad working arc angles which can be adjusted to a convenient right angle. It is constructed of engineering plastic and stainless steel for maximum corrosion protection and long life. With the MXY-4000, positioning an ultrasonic transducer is smooth and responsive. This is accomplished with the precision worm gears through manual knobs that allow angular motion of 170° on axis 1 and 184° on axis 2.
| Dimensions | 3.52" x 3.13" x 1.67" |
| Backlash | Less than 6 Arc minutes |
| Resolution | Infinitely adjustable |
| Readouts | 10° Increments Azimuth |
| Range | +/- 93° gimbal axis, +/- 49° swivel axis |
| Positioning | Infinitely adjustable |
| Connector | UHF Male Thread (top), UHF Female Thread (sensor end) |
| Weight | 12 ounces |
