Echo Ultrasonics HiTempco High Temperature Couplant

Introduced in the mid 1970's by Krautkramer Branson and sold by GE Inspection Technologies, HiTempco has been the standard of performance in silicone based ultrasonic couplants for decades.

Product Description Product Specifications

has a very high viscosity.

With a broad temperature range of -50° to 775°F (-45° to 412°C), its applications range from high temperature thickness gauging and flaw detection to ambient and low temperature coupling where no corrosion, broad material compatibility, long service life and low toxicity are considerations.

HiTempco has an Instantaneous ultrasonic response - does not contain plastic powders which delay ultrasonic conduction and result in difficult-to-remove residues.

Excellent low-term corrosion inhibition providing non-toxic, long-term corrosion inhibition for steel and cast iron and is compatible with other metals and most plastics.

HiTempco may be left in place unless it will interfere with subsequent manufacturing operations such as painting or electroplating.

Low environmental impact. Contains no perfluorocarbons, peanut or tree nut oils.

Operating Range: -50° to 775°F (-45° to 412°C)

Viscosity: ≈40,000 cps. Brookfield

Flash Point: Cleveland Open Cup 649°F (343°C)

Auto Ignition: 894°F (479°C)

HT-02 - 2 oz metal tube
HT-04 - 4 oz metal tube
HT-25 - 1 quart (Rigid open-top container)
HT-1GA - 1 gallon (Rigid open-top container)


Wipe with paper or cloth rag.

Note: Minimum order for Echo Couplant is $75. For orders that do not meet our minimum, there will be a $25 small order processing fee.

Description Part # Saved Price Select Option Add to
HiTempco: 2 fluid oz / 59 ml (volume) metal tube (minimum of 2) UT-EU-HT-02 $44.00
HiTempco: 4 fluid oz / 118 ml (volume) metal tube UT-EU-HT-04 $85.00
HiTempco: Quart / .95 liter collapsible cubitainer, bottle, dispensing tap UT-EU-HT-25 $333.00
HiTempco: 1 gal / 3.8 liter collapsible cubitainer, bottle, dispensing tap UT-EU-HT-1GA $1,277.00
