Technisonic Angle Beam Probes

Technisonic Angle Beam Probes

Made with Durable Stainless Steel Housing with Excellent Gain and Signal/Noise Ratios with Wedge

 Rugged Angle Beam Probes

Technisonic offers a complete line of Angle Beam Transducers (ABS) compatible with all commercially available flaw detectors. These are longitudinal wave transducers which can generate shear waves when coupled to a Technisonic wedge. They are primarily used for weld inspection or flaw detection of defects with favorable orientation. Constructed within a stainless steel housing for durability and rugged dependability. An acoustically matched epoxy lens insures optimum performance and color coded labels make them easy to identify. When coupled to a Technisonic Wedge, these transducers provide excellent gain and signal/noise ratios.

Supplied with a BNC connector, other connectors are available on special order.

Angle Beam Transducers and Wedges have a 6-32 Screw Size, unless 4-40 is specifically requested.

Wedges

Serrated Wedges (WSR)

Used for standard angle beam transducers and offers excellent signal/noise ratios.

High Temperature Wedges (WHT)

Best suited for elevated temperatures up to 550°F. These high temperature wedges are made from "Technitherm" and are designed to reduce drift and attenuation as compared to other materials. Intermittent use at elevated temperatures is recommended, to avoid transducer overheating.

Technical Specifications

Angle Beam Transducers (ABS) Dimensions

Element A B C D
.50" Diameter .75" 1.00" .70" .81"
.50" x 1.0" .75" 1.62" .70" 1.31"
1.0" Diameter 1.25" 1.65" .73" 1.38"
.75" x 1.0" 1.00" 1.56" .73" 1.31"

Purchasing Details

General Purpose (GP) Angle Beam Transducers (ABS)

Frequency Element Size
  .50" Diameter .50" x 1.0" .75" x 1.0" 1.0 Diameter
0.5 MHz - - - ABS-0008-GP
1.0 MHz ABS-0104-GP ABS-010408-GP ABS-010608-GP ABS-0108-GP
2.25 MHz ABS-0204-GP ABS-020408-GP ABS-020608-GP ABS-0208-GP
3.5 MHz ABS-0304-GP ABS-030408-GP ABS-030608-GP ABS-0308-GP
5.0 MHz ABS-0504-GP ABS-050408-GP ABS-050608-GP ABS-0508-GP
Serrated Wedges (WSR)

Transducer Size Effective Angle (Steel)
  45° 60° 70° 90°
.5" Diameter WSR-04-45 WSR-04-60 WSR-04-70 WSR-04-90
.5" x 1" WSR-0408-45 WSR-0408-60 WSR-0408-70 WSR-0408-90
.75" x 1" WSR-0608-45 WSR-0608-60 WSR-0608-70 WSR-0608-90
1" Diameter WSR-08-45 WSR-08-60 WSR-08-70 WSR-08-90
  • Screw Holes have a 6-32 thread, 4-40 is also available
  • Special angles and curvatures are available on special order



High Temperature Wedges (WHT)

 Transducer Size Effective Angle (Steel)
   45°  60°  70°
 .5" Diameter  WHT-04-45  WHT-04-60 WHT-04-70
 .5" x 1"  WHT-0408-45  WHT-0408-60 WHT-0408-70
.75" x 1"   WHT-0608-45  WHT-0608-60 WHT-0608-70
1" Diameter   WHT-08-45  WHT-08-60 WHT-08-70
  • Screw Holes have a 6-32 thread, 4-40 is also available
  • Special angles and curvatures are available on special order
  • Wedges designed for temperatures above 550 °F are also available
  • Cooling Cycle: Allow transducer to cool to ambient temperature after 30 seconds @ 400 °F
Description Part # Saved Price Select Option Add to

Probes
Technisonic General Purpose Angle Beam Probe, 0.5 MHz, BNC-Top (specify size)
Model #
UT-TS-ABS-0008-GP-Master
$405.00
Technisonic General Purpose Angle Beam Probe, 1 MHz, BNC-Top (specify size)
Model #
UT-TS-ABS-0100-GP-Master
$370.00
Technisonic General Purpose Angle Beam Probe, 2.25 MHz, BNC-Top (specify size)
Model #
UT-TS-ABS-0200-GP-Master
$365.00
Technisonic General Purpose Angle Beam Probe, 3.5 MHz, BNC-Top (specify size)
Model #
UT-TS-ABS-0300-GP-Master
$365.00
Technisonic General Purpose Angle Beam Probe, 5 MHz, BNC-Top (specify size)
Model #
UT-TS-ABS-0500-GP-Master
$365.00

Wedges
Technisonic Serrated Wedges, 1/2" x 1/2" (specify angle)
Model #
UT-TS-WSR-04-Master
$69.00
Technisonic Serrated Wedges, 1/2" x 1" (specify angle)
Model #
UT-TS-WSR-0408-Master
$71.00
Technisonic Serrated Wedges, 3/4" x 1" (specify angle)
Model #
UT-TS-WSR-0608-Master
$88.00
Technisonic Serrated Wedges, 1" x 1" (specify angle)
Model #
UT-TS-WSR-08-Master
$88.00
Technisonic High Temperature Wedge, 1/2" x 1/2" (specify angle)
Model #
UT-TS-WHT-04-Master
Request Pricing
Technisonic High Temperature Wedge, 1/2" x 1" (specify angle)
Model #
UT-TS-WHT-0408-Master
Request Pricing
Technisonic High Temperature Wedge, 3/4" x 1" (specify angle)
Model #
UT-TS-WHT-0608-Master
Request Pricing
Technisonic High Temperature Wedge, 1" x 1" (specify angle)
Model #
UT-TS-WHT-08-Master
Request Pricing
