Panoramic Crawlers for Pipeline Inspection

Overview

ICM's SiteX Crawlers are capable of providing the direct and accurate measurement of high voltage. This essential information enables the control system to guarantee the stability and reproducibility of the radiological parameters based on true high voltage, ensuring extremely precise measurements-based utilization. This device allows a 100% working cycle under completely safe conditions and also reduces the anode temperature by 50%, which in turn enables you to use the SiteX Series without ever having to let it cool down. These crawlers come equipped with a patented automatic beam correction system. Perfect homogeneity is provided thanks to a real time feedback loop adjustment and an EMR (Executive Means Ratio) value of less than 5%.

Perfect for inspection of pipelines up to 60 mm/2.7” of steel at unprecedented low price points.

Features

  • Ruggedized, IP65 rating
  • 360º x 40º panoramic beam
  • Focal spot of 0.5 x 0.8 mm
  • Weight ranges from 28 to 32 kg depending on the model
  • Perfect for pipeline inspection
  • Highly efficient heat exchanger
    • 100% working cycle functioning under completely safe conditions, which will simultaneously reduce the anode temperature by 50%
  • Auto-correction X-ray beam
    • Perfect homogeneity is provided thanks to a real-time feedback loop adjustment and an EMR (Executive Means Ratio) value of less than 5%.

Models

Model kV Amp Weight Focal Spot EN 12543 Radiation Coverage
SiteX C2004 200 kV 1 to 4 mA 61.7 lbs. (28kg) 0.5 x 0.8 mm 360º x 40º
SiteX C2254 225 kV 1 to 4 mA 61.7 lbs. (28kg) 0.5 x 0.8 mm 360º x 40º
SiteX C2504 250 kV 1 to 4 mA 61.7 lbs. (28kg) 0.5 x 0.8 mm 360º x 40º
SiteX C3005 300 kV 1 to 5 mA 70.5 lbs. (32kg) 0.5 x 0.8 mm 360º x 40º
SiteX C3205 320 kV 1 to 5 mA 70.5 lbs. (32kg) 0.5 x 0.8 mm 360º x 40º

To see more specifications, please view the below product literature:

SiteX Crawler Brochure SiteX Crawler Catalog

CCU186 Remote Control Unit

The CCU186 control unit for crawlers possesses a distinct advantage compared to existing products. In fact, all of the performances that are usually achieved with standard control units are now available in the crawler configura­tion. Automatic slow preheating, the progressive rise in voltage with each exposure, as well as a selection of set values are all included in the CCU186. As the CCU186 has been entirely fitted with industrial electronic components, it is perfectly suited to the often extreme conditions of automatic intra-tube control campaigns.
