MagWerks Demagnetizers

MagWerks Demagnetizers

MagWerks Demagnetizers

CD1915 Continuous Duty
Coil Size: 19" wide x 15" tall internal
Standard Features:
  • Thermal Overload Protection
  • 12,000 Ampere - Turn Rating
  • 19" Wide x 15" Tall Opening
  • Outside Dimensions: 261/4" Wide x 221/4" Tall
  • Stainless Steel Inner Liner
  • Stainless Steel Outer Covering
  • Stainless Steel Mounting Feet
  • Pilot Light for Line Power
  • External Wiring Box
  • Forced Air Cooling

MagWerks Demagnetizers

CD11212 Continuous Duty
Coil Size: 12" wide x 12" tall internal
Standard Features:
  • 240VAC / 480VAC 60Hz 1 Phase Input
  • 7,500 Ampere - Turn Rating
  • 12" x 12" Opening Size
  • Outside Dimensions: 20" Tall x 20" Wide x 14" Deep
  • Stainless Steel Inner Liner
  • Stainless Steel Outer Covering
  • Stainless Steel Mounting Feet
  • Pilot Light for Line Power
  • External Wiring Box
  • Forced Air Cooling
Free Standing AC Demagnetizer













Free Standing AC Demagnetizer

Free Standing AC Demagnetizers
FM-1012
10" x 12"
9,100 or 15,400 Ampere Turns
FM-1416
14" x 16"
9,100 or 13,500 Ampere Turns
FM-2225
22" x 25"
9,100 or 12,000 Ampere Turns
FM-2630
26" x 30"
9,100 or 13,500 Ampere Turns
FM-3030
30" x 30"
9,100 or 13,500 Ampere Turns
Standard Features
  • 240VAC / 480 VAC 60Hz 1 Phase Input
  • Thermal Overload Protection
  • External Adjustable Electronic Timer
  • Non-Ferrous Coil Core
  • Pilot Light for Line Power
  • Push Buttons on Each Side to Start Demag Cycle
  • Field Retrofittable Track and Carriage or Table Tops
  • NEMA 12 Electrical Enclosure
  • Master Disconnect - Fused
  • Ring Down Bank to Prevent Accidentally Remagnetizing the work pieces
  • Paint Color - MagWerks Tan Baked Powder Coating
  • Operator's / Maintenance Manual in English

ac demagnetizers - round  ac demagnetizers - rectangular

AC Demagnetizers
Round Rectangular
3.5" 4" x 7"
4.5" 4" x 9.5"
6" 4.5" x 14"
10" 6" x 14"
  8" x 14"
  8" x 24"
  14" x 16"
Options:
  • 110, 220, 480VAC
  • Continuous or Intermittent Operation
  • Dry or wet
Parts Conveyor with Inspection Area and Demag

parts conveyor with inspection area and demag

814HS-RDC 8" x 14" Reversing Demagnetizer

8x14 reversing dc demagnetizer
